نظرة عامة:
10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage

الوصف والمميزات:
Dream Machine Pro Max
10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.
Specifications
Mechanical
Dimensions
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
Weight
4.7 kg (10.4 lb)
Enclosure Material
Aluminium CNC, SGCC steel
Mount Material
SGCC steel
Hardware
Processor
Quad-core ARM® Cortex®-A57 at 2.0 GHz
System Memory
8 GB DDR4
On-board Storage
32 GB eMMC
Integrated SSD
128 GB
Management Interface
Ethernet, Bluetooth
Networking Interface
LAN
(8) GbE RJ45 ports, (1) 10G SFP+ port
WAN
(1) 2.5 GbE RJ45 port, (1) 10G SFP+ port
IDS/IPS Throughput
5 Gbps*
*Measured with iPerf3; performance may vary with PPPoE.
Power
Power Method
Universal AC input: 100—240V AC, 2A Max., 50/60 Hz
USP-RPS DC input: 11.5V DC, 8.7A
Power Supply
AC/DC, internal, 100W
Supported Voltage Range
100—240V AC
Max. Power Consumption
100W
ESD/EMP Protection
Air: ± 15kV, contact: ± 8kV
LCM Display
Display
1.3" touchscreen
Button
Factory reset
Environmental
Operating Temperature
-10° to 40° C (14° to 104° F)
Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Gateway Features
Performance
Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
LTE Backup for internet failover
Internet quality and outage reporting
Next-generation Security
Application-aware firewall rules
Signature-based IPS/IDS
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall
Advanced Networking
License-free SD-WAN
WireGuard, L2TP, OpenVPN server
OpenVPN client, site-to-site VPN
Policy-based WAN and VPN routing
DHCP relay, customizable DHCP server
IGMP proxy, IPv6 ISP support
LED Indicators
Ethernet
Green: link/activity
SFP+
Green: link/activity
HDD
White: disk activity, Amber: disk error
RPS
Blue: ready
