نظرة عامة:
اكسس بوينت داخلى اكسس بوينت يويقيتى UNIFI AC-LITE
الوصف والمميزات:
Dual-Radio Performance, Gigabit Speeds
The UniFi AC Lite AP delivers 5x the performance of the first-generation UniFi AP while still maintaining Ubiquiti’s disruptive pricing strategy.
Sleek, Ultra-Compact Design
The UniFi AC Lite AP features a cleaner design in a reduced footprint – half the size compared to the standard UniFi AP.
Designed for Optimal RF Performance
The newly redesigned UniFi Controller optimizes RF performance:
Scalable Enterprise Wi-Fi Management
The UniFi Controller v4 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.
UNIFI
Dimensions
160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24")
Weight
170 g (6.0 oz), 185 g (6.5 oz) with Mounting Kits
Networking Interface
(1) 10/100/1000 Ethernet Port
Ports
No
Buttons
Reset
Antennas
(2) Dual-Band Antennas, 3 dBi Each
Wi-Fi Standards
802.11 a/b/g/n/ac
Power Method
Passive Power over Ethernet (24V), (Pairs 4, 5+; 7, 8 Return)
Power Supply
24V, 0.5A Gigabit PoE Adapter
Maximum Power Consumption
6.5W
Max TX Power
20 dBm
BSSID
Up to Four per Radio
Power Save
Supported
Wireless Security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Certifications
CE, FCC, IC
Mounting
Wall/Ceiling (Kits Included)
Operating Temperature
-10 to 70° C (14 to 158° F)
Operating Humidity
5 to 95% Noncondensing
ADVANCED TRAFFIC MANAGEMENT
VLAN
802.1Q
Advanced QoS
Per-User Rate Limiting
Guest Traffic Isolation
Supported
WMM
Voice, Video, Best Effort, and Background
Concurrent Clients
200+
SUPPORTED DATA RATES (MBPS)
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac
6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11b
1, 2, 5.5, 11 Mbps
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
