نظرة عامة:
Ubiquiti UniFi WiFi 6 Lite Access Point U6-lite

الوصف والمميزات:
U6 Lite
Discretely install the compact
Unifi 6 Lite AX1500 Dual-Band PoE-Compliant Access Point
from
Ubiquiti Networks
on a wall or ceiling using the included hardware for fast and reliable 802.11ax network coverage in your office or business. Designed to operate in congested areas, the Unifi 6 Lite wirelessly transfers data at up to 1501 Mb/s over the 2.4 GHz and 5 GHz frequencies and is powered through its Gigabit Ethernet port when connected to a PoE-compatible network switch or router. It also supports over 300 concurrent clients and can be remotely configured, managed, and monitored through the UniFi Network Controller software.
Key Features
Wi-Fi 6 (802.11ax)
Up to 1501 Mb/s Throughput
2.4 GHz / 5 GHz (Dual-Band)
1 x PoE-Compliant Gigabit Ethernet Port
Wall and Ceiling Mountable
WPA-PSK / WPA-Enterprise Authentication
Compact Design
Supports UniFi Network Controller
Wi-Fi 6 Access Point with dual-band 2x2 MIMO in a compact design for low-profile mounting.
UniFi 6 Lite is a 2x2 Wi-Fi 6 access point that delivers up to 1.5 Gbps aggregate radio rate with 5 GHz (MU-MIMO and OFDMA) and 2.4 GHz (MIMO) radios. Mount UniFi 6 Lite horizontally in the ceiling to cover a high-density environment, or mount it vertically on the wall to extend its range. UniFi 6 Lite has a compact and nano-sized design, so it can use nanoHD covers and mounting accessories.
Less interference with OFDMA
With OFDMA, Wi-Fi 6 access points not only deliver higher-volume data packets, but tactically parse and deliver data to multiple devices simultaneously, drastically improving their upload and download speeds.
A Secure Dock
Feel safe and secure from the moment you log in. The HP Thunderbolt G4 Dock with HP Sure Start prevents hackers from using the dock to attack the network and the attached notebook. Everything connected to this dock is protected and meets full NIST 800-193 requirements.
Expanded Compatibility, Easy Connectivity
Focus on your work and not your compatibility with a dock that works seamlessly with most notebooks and operating systems. Whether you use Windows, Mac, or Chrome OS, rigorous testing and certifications ensure that one USB Type-C cable connects your device and peripherals without issue.
The Power to Be Productive
Multitask, create, and collaborate faster with a dock that supports up to four 4K displays through Thunderbolt 4 technology and has double the Ethernet speed for faster downloads. This dock also delivers up to 100W of power, which is enough to charge most notebooks.
Device Management Made Easy
Manage your mixed fleet more efficiently with wired Intel vPro support that allows authorized administrators to remotely access and manage vPro-enabled notebooks using wired connections to make updates. IT Managers can also plan dock firmware updates anytime, even after the user disconnects through HP's One Click Installer.
Modern Device Manageability
With Intel vPro Active Management Technology, authorized administrators can remotely access notebooks using wired connections, even if turned off, to make updates.
Electronic Asset Management for Your Docks
Empower your IT to manage and track your docks by product name, serial number, and MAC Address from anywhere with the time-saving, user-friendly Electronic Tag (eTag) asset management tool
One Cable
With 120W from one cable, you can power mainstream systems.
HP Tests So You Can Rest
Rigorous testing helps assure dock compatibility across select HP notebooks and select Apple, Dell, and Lenovo notebooks with USB Type-C power ports.
More Ports, More Flexibility
More ports means more capabilities. With a Thunderbolt 4, HDMI, two USB Type-C, two DisplayPorts, four USB Type-A ports, and an RJ45 port, you can connect multiple devices like a keyboard and mouse.
Specification
Mechanical
Dimensions
Ø160 x 33 mm (Ø6.3 x 1.3")
Weight
Without mount: 300 g (10.6 oz)
With mount: 315 g (11.1 oz)
Enclosure material
Polycarbonate, aluminum
Mount material
Polycarbonate, SGCC steel
Hardware
Networking interface
(1) GbE RJ45 port
Management interface
Ethernet
Bluetooth
Power method
PoE
Passive PoE, 48V
Power supply
PoE
48V, 0.32A PoE adapter (Not included)
Supported voltage range
44—57V DC
Max. power consumption
12W
Max. TX power
2.4 GHz
5 GHz
6 GHz
23 dBm
23 dBm
–
MIMO
2.4 GHz
5 GHz
6 GHz
2 x 2
2 x 2
–
Throughput rate
2.4 GHz
5 GHz
6 GHz
300 Mbps
1201 Mbps
–
Antenna gain
2.4 GHz
5 GHz
6 GHz
2.8 dBi
3 dBi
–
LEDs
White/blue
Button
Factory reset
Mounting
Wall, ceiling (Included)
Operating temperature
-30 to 60° C (-22 to 140° F)
Operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Software
WiFi standards
802.11a/b/g/n/ac/ax
Wireless security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID
8 per radio
VLAN
802.1Q
Advanced QoS
Per-user rate limiting
Guest traffic isolation
Supported
Concurrent clients
300+
Supported Data Rates
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
1, 2, 5.5, 11 Mbps
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5)
6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11ax (WiFi 6)
7.3 Mbps to 1.2 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80)
Application Requirements
UniFi Network
Version 5.14.3 and later
